TE Connectivity “Inventory expansion : Heat Shrink Tubing”
![](https://www.kanetuu.co.jp/en/wp-content/uploads/sites/2/2024/01/dd4392_329dc7a6bb90432ba57c51fa613b358bmv2.jpg)
・TE’s Raychem brand of tubing was developed when our scientists pioneered the application of radiation crosslinking and the development of heat-shrinkable polymer products
・Today TE is recognized worldwide for its expertise in these areas.
Versafit V4:Characteristics
-
2:1 shrink ratio
-
Very thin wall provides space savings and rapid shrinking
-
Low shrink temperature further reduces installation time and risk of damage to temperature-sensitive components
-
Very flexible; doesn’t easily wrinkle when bent
-
Free of polybrominated biphenyls (PBBs) and polybrominated biphenyl oxides and ethers (PBBOs and PBBEs), which are classified as environmentally hazardous substances
-
RoHS compliant
-
Minimum shrink temperature: 70°C [158°F]
-
Minimum full recovery temperature: 90°C [194°F]
-
Operating Temperature Range : -30°C to 125°C [-22°F to 257°F]
Versafit V4:Details
*Wall thickness will be less if tubing recovery is restricted during shrinkage.
RNF-100:Characteristics
-
2:1 shrink ratio
-
Superior abrasion and solvent resistance when compared with that of many flexible, general purpose polyolefin tubings
-
Excellent physical, chemical, and electrical properties that meet or exceed industrial and military standards for highly reliable, general purpose tubing
-
Flexible; conforms to irregular shapes
-
Flame-retardant (colors only)
-
Wide range of sizes and colors
-
RoHS compliant
-
Minimum shrink temperature: 95°C [203°F]
-
Minimum full recovery temperature: 121°C [250°F]
-
Operating Temperature Range : -55°C to 135°C [-67°F to 275°F]
RNF-100:Details
*Wall thickness will be less if tubing recovery is restricted during shrinkage.
ES2000:Characteristics
-
4:1 shrink ratio allows a few sizes to cover a wide range of splice and component diameters
-
Flame-retardant and mechanically tough, the tubing provides strain relief and abrasion protection of wire splices, terminals, and other components
-
Thick adhesive liner forms an effective barrier against fluids and moisture and performs well at an extended temperature range
-
UL recognized
-
RoHS compliant
-
Minimum shrink temperature: 110°C [230°F]
-
Minimum full recovery temperature: 135°C [275°F]
-
Operating Temperature Range : -40°C to 130°C [-40°F to 266°F]
ES2000:Details
*Wall thickness will be less if tubing recovery is restricted during shrinkage.
ATUM:Characteristics
-
3:1 and 4:1 shrink ratios allow for connector-to-cable sealing
-
Tubing environmentally seals and protects components and interconnections
-
Medium wall provides increased mechanical protection
-
The adhesive in ATUM tubing bonds to a wide variety of plastics, rubbers, and metals, including polyethylene, aluminum, steel, and copper
-
RoHS compliant
-
Minimum shrink temperature: 80°C [176°F]
-
Minimum full recovery temperature: 110°C [230°F]
-
Operating Temperature Range : -55°C to 110°C [-67°F to 230°F]
ATUM:Details
*Wall thickness will be less if tubing recovery is restricted during shrinkage.
Please contact the planning division for questions and estimates.
TEL:075-662-0996
FAX:075-662-1184
